壓路機與傳統光面壓路機相比有什么優勢？

來源：http://www.gdglass.com.cn/ 日期：2022-06-27

相信很多人都見過壓路機，其主要工作原理是利用振動將路面碾壓密實，使之具有一定強度和穩定性，以保證行車安全。由于振動可以提高道路質量，所以也常被稱作"軟土地基處理法",簡稱振動法。在公路建設中，廣泛應用于壓實、各種非粘性土壤、礫石、碎石混合料和各種瀝青混凝土。在的振動輪內，安裝有偏心塊軸、油馬達、減振環和連接架。

I believe many people have seen the road roller. Its main working principle is to use vibration to compact the road surface, so that it has a certain strength and stability, so as to ensure driving safety. Because vibration can improve road quality, it is also often called "soft soil foundation treatment method", which is called vibration method for short. In highway construction, it is widely used in compaction, all kinds of non cohesive soil, gravel, gravel mixture and all kinds of asphalt concrete. An eccentric block shaft, an oil motor, a damping ring and a connecting frame are installed in the vibrating wheel.

這種壓實壓路機的壓實原理是利用機器的高頻率振動與被壓材料的顆粒共振，從而減少材料顆粒之間的摩擦力，使被壓層容易壓實。工作時，路面上有兩種壓力。一個是動作用力；另一個就是靜力作用。

The compaction principle of this compaction roller is to use the high-frequency vibration of the machine to resonate with the particles of the compacted material, so as to reduce the friction between the material particles and make the compacted layer easy to compact. When working, there are two kinds of pressure on the road. One is to use force; The other is static force.

前者包括兩個部分：一是動載荷；二是摩擦力，即輪胎與地面之間的相互作用力及車輪自身重力等。后者又可分為兩種情況。一種是靜作用力,整個壓路機的重量在前輪上.另一種是動力，使用偏心塊，輪子以min1000-3000次的頻率振動。

The former includes two parts: one is dynamic load; The second is friction, that is, the interaction between the tire and the ground and the gravity of the wheel itself. The latter can be divided into two cases. One is static force, and the weight of the whole roller is on the front wheel The other is power. Eccentric blocks are used, and the wheels vibrate at a frequency of 1000-3000 times.
濟南壓路機出租

當輪子內的馬達轉動時，會使振動軸一起轉動，使偏心塊周期性運動。如果我們把這個偏心塊固定在上面，那么這個偏心塊與地面之間存在著一定距離，這就是人們所說的摩擦力。當它旋轉到車輪的頂部時，產生的偏心力使輪子向上移動。當它在輪子下移動時，它驅動輪子形成向下的力。這個偏心塊在輪子內部旋轉，創造了一個錘擊運動向上和向下的外部碾壓輪。這種錘擊作用可以使路面更緊湊、更堅實。

When the motor in the wheel rotates, the vibrating shaft will rotate together, making the eccentric block move periodically. If we fix the eccentric block on it, there is a certain distance between the eccentric block and the ground, which is what people call friction. When it rotates to the top of the wheel, the eccentric force generated moves the wheel upward. When it moves under the wheel, it drives the wheel to form a downward force. This eccentric block rotates inside the wheel, creating a hammering motion up and down the outer roller. This hammering action can make the pavement more compact and solid.

那么，壓路機與傳統光面壓路機相比有哪些優勢呢？

Then, what are the advantages of the roller compared with the traditional smooth roller?

濟南壓路機出租人員認為在壓實砂性土情況下，重量為2噸的振動式壓路機的壓實效果可與重量為6噸的靜力光面壓路機相媲美。但由于采用了振動器和液壓系統，使其具有結構簡單、操作方便、成本低等特點。在我國南方地區已得到廣泛使用，且取得良好的經濟技術效益。與自重光面壓路機相同，壓實深度更深，壓實效果更好。

The lessor of Jinan roller believes that the compaction effect of a 2-ton vibratory roller can be comparable to that of a 6-ton static smooth roller under the condition of compacting sandy soil. However, due to the use of vibrator and hydraulic system, it has the characteristics of simple structure, convenient operation and low cost. It has been widely used in southern China and has achieved good economic and technological benefits. The same as the self weight smooth roller, the compaction depth is deeper and the compaction effect is better.

以上就是問題解答的相關內容了，希望能夠幫助到大家，如對這一問題還存在任何疑問，都歡迎關注我們網站http://www.gdglass.com.cn并咨詢我們的工作人員，將竭誠為您服務。

The above is the relevant content of the question answer. I hope it can help you. If you still have any questions about this problem, you are welcome to follow our website http://www.gdglass.com.cn And consult our staff, will serve you wholeheartedly.
